PowerFloor+
Luca group
Luca group
For this project, Hebel was a "no-brainer". A lightweight flooring solution, that also enhanced fire and acoustic requirements.
The PowerFloor+ system consists of extremely strong panels, containing caged steel reinforcement for span strength with an anti-corrosion coating on the steel for maximum durability.
The panels fit firmly together with tongue and groove joints to form a smooth and strong floor, without the need to wait for concrete to cure and with limited propping. Interlocking the PowerFloor+ panels with grout creates a full fire seal allowing the PowerFloor+ System to achieve Fire Resistance Levels (FRLs) of up to 3 hours without relying on ceiling systems.
Performance and benefits
Strong & solid
150-250mm thick caged steel reinforced panel, with load bearing span up to 5.85mt.
Quality & speed
Eliminates need for joist system, or the pouring and curing of concrete.
Fire resistant
Interlocking panels create a full fireseal between panels, achieving an FRL of up to 180mins without relying on ceiling systems.
Noise reduction
Reduces noise transfer between floors.
Applications
View by
Technical information
Load-bearing and spanning up to 5.85m without floor framing or joists, PowerFloor+ is lightweight compared to a traditional concrete slab. Lighter loads achieved by using Autoclaved Aerated Concrete (AAC) panels helps reduce structural requirements like slabs, columns, and footings. Also, PowerFLoor+ is made to length resulting in less wastage.
The PowerFloor+ system achieves excellent thermal performance, ensuring thermal ratings are easily met, and once finished it can be covered with a variety of commercial grade floor coverings, making it the ideal choice for commercial or apartment building floors.
PowerFloor-plus
| Product Code | Web Description | Width (mm) | Length (mm) | Thickness (mm) | Mesh Design | Weight Per Pack (kg) | Units Per Pack |
|---|---|---|---|---|---|---|---|
| MTO 11 | Made to Order PowerFloor+ | 600 | Up to 6000 | 150 | Caged | - | 5 |
| MTO 14 | Made to Order PowerFloor+ | 600 | Up to 6000 | 175 | Caged | - | 4 |
| MTO 17 | Made to Order PowerFloor+ | 600 | Up to 6000 | 200 | Caged | - | 4 |
| MTO 20 | Made to Order PowerFloor+ | 600 | Up to 6000 | 225 | Caged | - | 3 |
| MTO 23 | Made to Order PowerFloor+ | 600 | Up to 6000 | 250 | Caged | - | 3 |
Product accessories
Adhesives, Sealants & Coatings
Product name
Hebel Adhesive
SKU
21933
Use
All systems
Selling Unit
20kg Bag
Product name
Hebel Patch
SKU
21949
Use
All systems
Selling Unit
10kg Bag
Product name
Hebel Anti – Corrosion Paint
SKU
25594
Use
Used to coat exposed reo
Selling Unit
500mL Container
Hand Tools
Product name
Levelling Plane
SKU
21892
Use
Levelling Hebel
Selling Unit
Each
Product name
Powerpanel Lifters 16mm
SKU
21901
Use
Handling system for PowerPanel
Selling Unit
Pack of 2
Product name
Powerpanel Trolley 2.4-2.7 Panels
SKU
21903
Use
Handling system for PowerPanel
Selling Unit
Each
Product name
Powerpanel Trolley 2.9-3.35 Panels
SKU
21904
Use
Handling system for PowerPanel
Selling Unit
Each
Product name
Sanding Float
SKU
21912
Use
All systems
Selling Unit
Each
Product name
Panel Scissor Lifter 75mm
SKU
107687
Use
Panel lifter
Selling Unit
Each
Product name
Panel Separator Kit
SKU
119426
Use
All systems
Selling Unit
Each
Product name
Installer Power Panel Trolley
SKU
130324
Use
Handling system for PowerPanel
Selling Unit
Each
Product name
2 Wheel Panel Mover
SKU
162645
Use
Handling system for PowerPanel
Selling Unit
Each
